Fiber Wood Insulation Internal 160kg/m³

Fiber Wood Insulation FiberTherm Internal density 160kg/m³

Fiber Wood Insulation with density 160 Kg/m³.
Fibertherm Internal 160 is a plasterable fiber wood panel used for thermal insulation system of internal walls. The panels have reduced thickness to occupy the smallest possible space, high compressive strength and are water-repellent.

The fiber wood panel FiberTherm Internal 160 is an insulator for the inside of the building walls: reducing the costs of heating can improve the lifestyle. The applications are many, compared to other types of internal insulation is also the most economical solution.

There are good reasons to realize an internal insulation: in case the façades can not be modified, if you want to isolate an apartment, or if the external walls of an old building need better insulation. In addition to this, you can improve the performance of internal insulation of poorly used buildings or rooms, such as holiday homes, common rooms or guest rooms - through the internal insulation, the rooms can heat up quickly. Furthermore, the installation of an internal insulation is often easier.
Scaffolding is not used and it is possible to intervene independently from atmospheric conditions. However, external isolation is still more effective. And that is why we recommend the use of internal insulation only in the cases described above.

The insulating fiber wood panels FiberTherm Internal 160 are ideal even in situations of limited space. Available with male / female profile or with sharp and flat edge. Density equal to 160 Kg/m³.

The material is also recyclable, it is certified and made exclusively with wood from controlled forests in compliance with the FSC guidelines.


The insulating fiber wood panels FiberTherm Internal 160 diffuse the steam and allow the capillary transport of the steam. FiberTherm Internal 160 protects the living area from molds as it provides an optimal moisture balance to create an environment in which mold is not formed.


The insulating fiber wood panel FiberTherm Internal 160 has the following characteristics:

• ecologic internal insulation;
• ideal for masonry and restoration of wood cladding;
• excellent humidity control - maximum safety;
• it can be used without additional anti-steam layers;
• brings a truly healthy and natural internal atmosphere;
• recyclable, ecologic, environment-friendly;
• building material tested and authorized according to current European standards.

Available sizes

fiber wood panels with sharp edges
Thickness Size mm kg/m² Pan./pallet m²/pallet kg/pallet
40 mm 1200 x 380 6,40 84 38,3 approx.260
60 mm 1200 x 380 9,60 57 26,0 approx.250
80 mm 1200 x 380 12,80 42 19,2 approx.270


Available sizes

fiber wood panels with tongue&groove edges
Thickness Size mm Real surface mm kg/m² Pan./pallet m²/pallet kg/pallet
40 mm 1200 x 380 1186 x 366 6,40 84 38,3 approx.260
60 mm 1200 x 380 1186 x 366 9,60 54 24,6 approx.250


Technical characteristics

Characteristics Values
Density kg/m³ 160
Fire reaction according to EN 13501-1 E
Coefficient of thermal conductivity λD W/(m∗K) 0,038
Specific heat J/(kg∗K) 2.100
Resistance to vapor diffusion μ 5
sd values (m) 0,2 (40) / 0,3 (60) / 0,4 (80)
Thermal resistance RD (m²·K)/W 1,0 (40) / 1,5 (60) / 2,0 (80)
Compression resistance (kPa) 50
Bending resistance [(kPa·s)m²] ≥100
Panels identification WF-EN 13171-T4
-CS(10/Y)50-TR2,5-AF100
Waste code (EAK) 030105/170201


Solution with Fiber Wood Internal

Internal thermal insulation system in Fiber Wood
Internal thermal insulation system in Fiber Wood

Internal thermal insulation system in fiber wood FiberTherm Internal with dedicated professional accessories.
